Roofing

ZIP-RIB

Stringently tested in the laboratory and field to assure superior performance, ZIP-RIB establishes the industry benchmark. ZIP-RIB panels accommodate the most complex roof configurations including convex and concave curves & tapers.

2'' ZIP LOK

A Single or Double locking standing seam panel system. Design professionals have an additional mechanically seamed panel system from Merchant & Evans to suit their application needs. 2" Zip-Lok is available in 12", 16" and 18" coverage with optional panel ribs clip offsets and striations.

1½" ZIP LOK

A Single or Double locking standing seam panel system. Design professionals have an additional mechanically seamed panel system from Merchant & Evans to suit their application needs. 1½" Zip-Lok is available in 12", 16" and 18" coverage with optional panel ribs clip offsets and striations.

CLASSIC RIB 305

Integral batten and pan system. Applications: Architectural roofing on slopes 3" or greater. Continuous lengths up to 45 ft. Vertical walls & conical tapers. Install on solid deck, plywood or rigid insulation over decking. Requires minimum 30# felt underlayment and rosin slip sheet.

TRADITIONAL RIB 306

Narrow seam system. Applications: Architectural roofing on slopes 3" or greater. Continuous lengths up to 45 ft. Vertical walls, conical tapers and radius barrels. Install on solid deck, plywood or rigid insulation over decking. Requires minimum 30# felt underlayment and rosin slip sheet.

BD-1520

Designed especially for complex roof applications and available as a functional architectural product, the Merchant & Evans Customform BD-1520 system accommodates a variety of curved designs, including domes, hips and barrel vaults, as well as tapered and straight-run projects.

B1515R

Applications: Architectural roofing on slopes 3" or greater. Continuous lengths up to 45 ft. Vertical walls, conical tapers and radius barrels. Install on solid deck, plywood or rigid insulation over decking. Requires minimum 30# felt underlayment. Requires rosin slip sheet for roof application.

114-R

Applications: Architectural roofing on slopes 3" or greater. Continuous lengths up to 45 ft. Vertical walls and conical tapers. Install on solid deck, plywood or rigid insulation over decking. Requires minimum 30# felt underlayment. Requires rosin slip sheet for roof application.
